Victron Blue Solar Charge Controller MPPT 150/45 up to 250/100

Victron Energy Logo
From £283.28
From £283.28
Sale Sold out
Shipping calculated at checkout.

These Victron Blue Solar Charge Controller supports a PV input with a maximum open circuit voltage of either 150V or 250V and have a maximum output of up to 100A. It works with and will automatically recognise 12V, 24V and 48V battery systems (36V also possible via software configuration).

See full details

Retail customers
Many of the products we supply require training and experience to install, we recommend seeking the assistance of a professional to help you with your project.

Find the right installer for you

Trade customers
Please login or apply for a trade account for trade pricing, check stock and order online.

Log in / Apply for a trade account

Select model

Variant Price (exc VAT)
VBS-MPPT150/60-TR
BlueSolar MPPT 60A/150V ch. controller 12/24/48V w/terminals
£283.28
£283.28
VBS-MPPT150/60-MC4
BlueSolar MPPT 60A/150V charge controller MC4
£283.28
£283.28
VBS-MPPT150/70-TR
BlueSolar MPPT 70A/150V ch. controller 12/24/48V w/terminals
£311.79
£311.79
VBS-MPPT150/70-MC4
BlueSolar MPPT 70A/150V charge controller 12/24/48V MC4
£312.69
£312.69
VBS-MPPT250/70-TR-CAN
BlueSolar MPPT 250A/70-TR VE. CAN
£441.85
£441.85
VBS-MPPT250/100-TR-CAN
BlueSolar MPPT 250A/100-TR VE. CAN
£541.62
£541.62
(exc VAT)
Login for trade prices

Victron Blue Solar Charge Controller MPPT 150/45 up to 250/100

These Victron Blue Solar Charge Controller supports a PV input with a maximum open circuit voltage of either 150V or 250V and have a maximum output of up to 100A. It works with and will automatically recognise 12V, 24V and 48V battery systems (36V also possible via software configuration).

Highlights:

  • Bluetooth enabled (Bluetooth dongle needed)
  • Ultra-fast Maximum Power Point Tracking (MPPT)
  • Advanced Maximum Power Point Detection in case of partial shading conditions
  • VE.Direct communication port
  • VE.Can models allow daisy chained communication
  • Available with 35 mm² screw terminals (TR) or 3 sets of MC4 connectors (MC4)
  • Up to 98% efficient
  • 8 preprogrammed algorithms selectable with a rotary switch
  • Electronic protection:
    • Over-temperature
    • PV short circuit, reverse polarity and reverse current
  • Internal temperature sensor, compensates absorption and float charge voltages
  • 5 years warranty

Quick Links

Technical Specifications

Downloads

Good to know

Technical Specifications

SKUVBS-MPPT150/60-TRVBS-MPPT150/60-MC4VBS-MPPT150/70-TRVBS-MPPT150/70-MC4VBS-MPPT250/70-TR-CANVBS-MPPT250/100-TR-CAN
System Battery Voltage 12V, 24V, 36V*, 48V 12V, 24V, 36V*, 48V 12V, 24V, 36V*, 48V 12V, 24V, 36V*, 48V 12V, 24V, 36V*, 48V 12V, 24V, 36V*, 48V
Max VOC 150V 150V 150V 150V 250V 250V
MPPT Trackers 1 1 1 1 1 1
Connectivity VE.Direct VE.Direct VE.Direct VE.Direct VE.Direct, VE.Can VE.Direct, VE.Can
Connection Screw terminals MC4 Screw terminals MC4 Screw terminals Screw terminals
Height 185 215 185 215 185 216
Width 250 250 250 250 250 295
Depth 95 95 95 95 95 103
Weight (kg) 3 3 3 3 3.6 6.2
Packaging Height 270 270 270 270 270 330
Packaging Width 250 250 250 250 250 290
Packaging Depth 150 150 150 150 150 160
Warranty 5 5 5 5 5 5
IP Rating IP43 (electronic components), IP22 (connection area) IP43 (electronic components), IP22 (connection area) IP43 (electronic components), IP22 (connection area) IP43 (electronic components), IP22 (connection area) IP43 (electronic components), IP22 (connection area) IP43 (electronic components), IP22 (connection area)
On Grid / Off Grid Off Grid Off Grid Off Grid Off Grid Off Grid Off Grid
Lithium Compatibility Yes* Yes* Yes* Yes* Yes* Yes*
Intrastat Commodity Code 85044055 85044055 85044055 85044055 85044055 85044055

Downloads / Documents

Related Products

1 2

*see manufacturer's documentation for further information
