Victron Cyrix Intelligent Load Relays
The Cyrix-Li-load will disengage when its control input becomes free floating. If the battery voltage recovers after disconnection (which will happen when no other loads are connected to the battery), the output of the BMS will become high and the Cyrix will reengage after 30 seconds. After 3 attempts to reengage, the Cyrix will remain disengaged until battery voltage has increased to more than 13 V (resp. 26 V or 52 V) during at least 30 seconds (which is a sign that the battery is being recharged).
Select model
| Variant | Price (exc VAT) | ||
|---|---|---|---|
|
VCRX-LI-L/120-12/24
Victron Cyrix-Li-load 12/24V-120A intelligent load relay |
Regular price
£57.91
Regular price
Unit price
per
|
||
|
VCRX-LI-L/230-12/24
Victron Cyrix-Li-load 12/24V-230A intelligent load relay |
Regular price
£144.31
Regular price
Unit price
per
|
||
Victron Cyrix Intelligent Load Relays
The Cyrix-Li-load will disengage when its control input becomes free floating. If the battery voltage recovers after disconnection (which will happen when no other loads are connected to the battery), the output of the BMS will become high and the Cyrix will reengage after 30 seconds. After 3 attempts to reengage, the Cyrix will remain disengaged until battery voltage has increased to more than 13 V (resp. 26 V or 52 V) during at least 30 seconds (which is a sign that the battery is being recharged).
Quick Links
Good to know
Technical Specifications
| SKU | VCRX-LI-L/120-12/24 | VCRX-LI-L/230-12/24 |
|---|---|---|
| System Battery Voltage | 12V, 24V | 12V, 24V |
| Weight (kg) | 0.14 | 0.27 |
| Packaging Height | 75 | 120 |
| Packaging Width | 65 | 110 |
| Packaging Depth | 50 | 110 |
| Warranty | 5 | 5 |
| Intrastat Commodity Code | 85364190 | 85364190 |
*see manufacturer's documentation for further information
