Schletter Fasteners for Roofs with Steel Sub-Structures
Designed especially for a safe fastening to corrugated fibre cement or trapezoidal sheet metal roofs on a steel substructure avoiding breakage and leaks.
-
Schletter Fix-Z-7 and Fix-Z-15
For flat trapezoidal sheet roofs with less than a 10-degree slope, module installation parallel to the roof is not always optimal, due to low yields and inadequate module self-cleaning.
-
Schletter FixGrid Pro Screw-in Tool
Useful to quickly align and fit Module Support Pro and Elevation Pro to Base Rail Pro
-
Schletter FixGrid Surface Protect Mat
For placing centrally under under each Base Rail support to protect the roof structure.
-
Schletter FixGrid18 Ballast Tray
Can be fastened between Base Rails to accomodate extra ballast.
-
Schletter FixGrid18 FixZ Supports
Use the lower FixZ support together with the FixZ centre supports (for the east-west direction) or with the upper FixZ profiles (for the south direction).
-
Schletter FixGrid18 Windsafe Sheet
Windsafe sheets with integrated ballast tray for theSouth facing applications.Used to provide the necessary ballasting in regions with higher wind loadings.
-
Schletter FixZ Pro
Flush mounted installations on low-pitch trapezoidal roofs may be less than ideal for self-cleaning and maximum yield. At the same time using conventional struts may not be possible or uneconomical due to higher loads. In these cases FixZ Pro offers flexibility, with a universal and cost-effective solution that optimises load transfer to the roof while providing optional tilt angles as desired.
-
Schletter Hanger Bolts
Used for fastening mounting rails to corrugated roofs. Hanger bolt is screwed through the roof cladding and an adaptor plate bears the mounting rail. A UV-resistant EPDM sealing washer and collar are used to seal the drilled hole.
-
Schletter ProLine End Caps
End Caps - one size to suit either 35, 50 or 70 mm mounting rails
-
Schletter ProLine Mounting Rails
- Material: Aluminium EN AW 6063 - T66
- Can be combined with roof hooks, connectors and module clamps of the ProLine series
- Can also be combined with the SingleFix Pro trapezoidal sheet fastener
-
Schletter ProLine Rail Joiners
Internal connector - for joining mounting rails
The integrated position lock means that no additional screw connection is required. -
Schletter ProLine Roof Hooks
These roof hooks are faster to install than ever.
They make quick and flexible installation possible by hooking in and is fastened with just one Torx pan head screw. The assembly is simplified by first, mounting the screw-on plate on the rafters and the snapping in the bracket afterwards.
*see manufacturer's documentation for further information
